SQA1200.1 | Class D Mono Amplifier 1200W X 1 @ 1 ohm
Regular price
$595.00
Regular price
Sale price
$595.00
Unit price
per
Product Highlights:
- Model number: SQA1200.1
- Channel / class: Mono / D
- RMS power at 2 ohm-14.4V: 1200W x 1
- RMS power at 1 ohm-14.4V: 800 x 1
- RMS power at 4 ohm-14.4V: 450 x 1
- Fuse rating: 30A x 4
-
Dimensions (inch): 10.6(w) x 1.9(h) x 7.3(d)
(mm): 270(w) x 48(h) x 185(d)
Description
The SQA Series amplifiers can produce their rated power with an efficiency of more than 80%! These Full Range Class D amplifiers will take it easy on your vehicles charging system while still rocking out to the max. Worry free defensive circuits which detect Short Circuit, Low Battery Voltage, Over Current and Thermal Protection which rollback power from damaging circumstances. The SQA Series have a small footprint for easy installation in tight spaces, and include a robust assortment of crossover adjustments to meet many types of installs and includes a Remote Level Control (1CH, 3CH, and 5CH only) for adjusting the intensity of your bass.
PERFORMANCE | SQA1200.1 |
---|---|
RMS power at 1 ohm (watts x channel) | 1200 x 1 |
RMS power at 2 ohm (watts x channel) | 800 x 1 |
RMS power at 4 ohm (watts x channel) | 450 x 1 |
THD at rated RMS power | Less than 0.05% |
Signal to noise ratio | >96 dB |
FEATURES | |
---|---|
Amplifier class | D |
Low pass filter | 50 – 150 Hz |
Subsonic filter | 10 – 50 Hz |
Bass Boost | 0 dB- 18 dB |
Fuse rating | 30A x 4 |
Speaker level input | RCA |
Width (inch / mm) | 10.6 / 270 |
Height (inch / mm) | 1.9 / 48 |
Depth (inch / mm) | 7.3 /185 |
